KC-EG4LFVRN KIDDE GENESIS G4LF WALL HORN-STROBE, FIRE, RED

Description

The EG4LFVRN Kidde Genesis G4LF Wall Horn-Strobe is a combined audible-visual notification device designed for life-safety fire-alarm systems. It delivers a low-frequency 520 Hz horn signal plus a clear-lens strobe light (15–110 cd, field-selectable) when an alarm is triggered, providing simultaneous audible and visual alerts to occupants. The unit mounts on a standard electrical box and integrates with compatible 24 V DC notification appliance circuits, offering synchronized horn and strobe output in compliance with applicable fire-alarm codes.

Model/SKU: KC-EG4LFVRN
Brand: Kidde
Function: Provides combined audible (low-frequency horn) and visual (LED strobe) alarm notification for fire/safety system zones.
Ratings: 16–33 V DC input (nominal 24 V DC); strobe selectable at 15, 30, 75, or 110 candela; horn output uses 520 Hz low-frequency tone.
Dimensions: Device housing protrudes ~1.5 in from wall when flush-mounted.
Material: Flame-rated thermoplastic housing.
Mounting / Connection: Wall-mount; fits standard 1-gang, 2-gang, 3.5-in octagon, and 4-in square electrical boxes; screw-terminal block accepts 12–18 AWG wiring.
Field-Configurable Output: Selectable candela for the strobe; selectable high/low dB and temporal or continuous horn output.
Synchronization: When used with compatible synchronization sources or panels, strobe output and horn can be synchronized to meet code (UL 1971) requirements for public-mode notification appliances.
Why It Matters: Combines audible and visual alarm signaling in a compact, code-compliant, low-profile device — ideal for multi-occupant buildings or locations requiring disability-accessible notification, while minimizing installation footprint and wiring load.
