KC-FX-RLY KIDDE FIRE ALARM RELAY MODULE

Description

The FX-RLY KIDDE FIRE ALARM RELAY MODULE is a supervised general-purpose relay interface designed for use with Kidde FX-series fire alarm control panels. It converts addressable panel instructions into isolated dry contact outputs, enabling remote control of auxiliary devices such as door holders, dampers, fan controls, elevator recall, or building management systems. The module supports supervised circuitry so panel logic can monitor relay status and report faults.

• Model/SKU: FX-RLY

• Brand: Kidde

• Function: Addressable relay interface that provides supervised dry contact outputs based on fire alarm control panel logic

• Outputs: Dry contact Form C relays for auxiliary control applications

• Compatibility: Designed for integration with Kidde FX-series fire alarm control panels

• Supervision: Monitors contact wiring and relay status for open/short conditions

• Mounting: Pluggable module or enclosure mounting with dedicated wiring terminals

• Application: Controls external devices (e.g., door holders, fans, HVAC cut-offs, elevator recall, security interfaces) based on alarm or supervisory panel conditions

• Why It Matters: Provides a reliable method for the fire alarm panel to actuate building systems and external equipment in response to fire or supervisory events while maintaining supervised integrity.
